Digital Lubricating Oils Filterability Test Equipment By ISO 13357

Brand Name : AI

Model Number : AIC-13357

Certification : ISO

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 20 sets per month

Delivery Time : 30 days

Packaging Details : Hardboard

Test standard : ISO 13357

Power supply : 220VAC 50Hz

Display : Digital

Pressure Control : precise pressure regulating valve

Rotating speed : 1500r/min ± 50 r/min

Dimension : 510*400*620mm3

Total power : 2500W

Weight : 38KG

Color : White

Timing mode : digital timer

Contact Now

Summary

This Lubricating Oils Filterability Test Equipment is produced according to SH/T 0805 standard and is used to determine the filterability of lubricating oil based on mineral oil, especially hydraulic oil in hydraulic system. It is not applicable to liquids based on other materials (such as flame retardant liquid, which may be compatible with the filter membrane used in this method).
This Lubricating Oils Filterability Test Equipment is also not applicable to some hydraulic oils with special properties because they contain insoluble or partially soluble additives or special macromolecular substances.

I. Main technical features

1. Glass fittings meet the standard requirements;
2. Digital display time, easy to operate, easy to observe;
3. The pressure can be controlled within the range of 86658Pa by precise pressure stabilizing valve;
4. The Lubricating Oils Filterability Test Equipment is designed as an integrated structure, which is convenient for operation;
5. The shell is made of high-quality cold-rolled steel plate, and the surface is treated by electrostatic spraying, which has good rust resistance and is easy to clean;
6. The Lubricating Oils Filterability Test Equipment has electronic agitator with stainless steel paddles and blades.

II. Main technical specifications

1	Test standard	SH/T 0805, ISO 13357
2	Timing mode	Digital display
3	Pressure control	precise pressure regulating valve adjustment, accurate control pressure ± 5 kPa
4	Solvent receiver	special solvent filter receiving bottle
5	Rotation mode	driven by reduction gear motor, automatic reverse
6	Mixing mode	Motor mixing, 1500r/min ± 50 r/min
7	Working power supply	AC220V 50Hz
8	Overall power	2500W
9	Dimension	510400620mm3
10	Weight	38KG
